  • NOSHOK 25-900-300-psi/kPa 1/4" NPT, 0 to 300 PSI/kPa, Brass Bottom Connection, 2-1/2" White Molded Plastic Dial, Liquid Filler, ABS Case, Dual Scale, Differential, Pressure Gauge
Picture of NOSHOK 25-900-300-psi/kPa 1/4" NPT, 0 to 300 PSI/kPa, Brass Bottom Connection, 2-1/2" White Molded Plastic Dial, Liquid Filler, ABS Case, Dual Scale, Differential, Pressure Gauge
IMPORTANT NOTE: This image (above) may or may not be the exact product image. It's used for illustration only. Please refer to the technical description and MPN for the exact product details. Contact us if you have ANY questions.
NISCO, Inc.

NOSHOK 25-900-300-psi/kPa 1/4" NPT, 0 to 300 PSI/kPa, Brass Bottom Connection, 2-1/2" White Molded Plastic Dial, Liquid Filler, ABS Case, Dual Scale, Differential, Pressure Gauge

MPN: 25-900-300-psi/kPa
List Price: $73.63
$36.90
Download Product Spec Sheet
Print this Page
Buying in Bulk?
Buying in Bulk?

Are you interested in buying this product in bulk? If so, please call our sales team and see if you qualify for a special bulk pricing discount.

REPLACEME
Need help?
Need help?

Are you unsure about which product you need to get the job done? If so, one of our friendly customer support representatives would be happy to help.

Please call us at REPLACEME2 and speak to an expert today.

Pressure Gauge | Pressure Gauge Type Differential | Minimum Pressure 0 PSI/Kilopascals | Maximum Pressure 300 PSI/Kilopascals | Display Type Dial | Enclosure Material ABS Plastic with Safety Relief Plug | End Connection 1/4 Inch Threaded | Connection Location Bottom | Sensor Element Copper Alloy C-Type Bourdon Tube | Dial Diameter 2-1/2 Inch | Dial Material Molded Plastic | Dial Color White Background with Black Primary Scale and Red Secondary Scale | Pointer Material Molded Plastic | Filler Material Liquid | Temperature Rating -40 to 140 Deg F | Full Scale Accuracy +/-1.6 Percent | Application Automotive, Construction, Hydraulic and Pneumatic, Power Generation, Transportation, Water Management | Scale Dual | Size 2.83 Inch Diameter x 2.13 Inch Width | Lens Material Acrylic | End Connection Material Brass

Manufacturer Catalog Page

Manufacturer Specification Sheet

Manufacturer Installation Instructions

Product Features / Technical Specifications
Features & Benefits Extremely High Quality Pressure Gauges Available in a Liquid Filled Version for Extended Service Life and Shock Resistance | Lightweight Shatter Resistant ABS Case with Acrylic Lens for Extra Strength or 304 Stainless Steel Case with Polycarbonate Lens |
Connection Location Bottom
Additional Information Scale Dual | Size 2.83 Inch Diameter x 2.13 Inch Width | Lens Material Acrylic | End Connection Material Brass
Application Automotive, Construction, Hydraulic and Pneumatic, Power Generation, Transportation, Water Management
Dial Color White Background with Black Primary Scale and Red Secondary Scale
Dial Diameter 2-1/2 Inch
Dial Material Molded Plastic
Display Type Dial
Enclosure Material ABS Plastic with Safety Relief Plug
End Connection 1/4 Inch Threaded
Filler Material Liquid
Full Scale Accuracy +/-1.6 Percent
Maximum Pressure 300 PSI/Kilopascals
Minimum Pressure 0 PSI/Kilopascals
Pointer Material Molded Plastic
Pressure Gauge Type Differential
Sensor Element Copper Alloy C-Type Bourdon Tube
Series/Model 900
Temperature Rating -40 to 140 Deg F
